Products Description
| The pull-out display light box is an extension of the mesh display stand. With its flexible structure, efficient lighting, and diverse customization features, the modular LED folding vertical background wall is made up of 75*75cm and 100*100cm squares extended vertically and horizontally. The mesh lock frame + silicone strip fabric combination, 30cm thickness makes the display stand generous and stable, simple to install and easy to transport. |
Product Features
-
Quick setup in 3 minutes, no tools required
The aluminum alloy mesh frame with locking design secures the edges and stabilizes the shelf, making setup easy even for first-time users. Say goodbye to tedious installation and save valuable setup time.
-
360° high brightness for more vivid images.
The side LED light strips emit uniform light (with a lifespan of up to 50,000 hours), paired with a 190g/m² anti-glare backlit canvas, resulting in 40% improved color saturation and clear image detail even from 20 meters away. The double-sided display design maximizes eye-catching appeal.
-
Modular splicing design, highly adaptable
Each module measures 30*30 inches and 39.4*39.4 inches respectively, and the splicing length can reach 40ft, L-shaped, C-shaped, and archway, meeting various display needs such as background walls and promotional standees. The image can be changed quickly, with a single update taking only 30 seconds.
-
Sturdy and durable, it's more cost-effective for long-term reuse.
The anodized aluminum alloy frame is corrosion-resistant, and the weighted base provides wind resistance up to level 3, making it suitable for long-term reuse at exhibitions. The frame comes with a 5-year warranty, while the LEDs and canvas have a 1-year warranty.
-
Customizable Designs
Personalization is crucial for advertising, and our pop-up displays offer customizable graphics to match your brand's unique style and message.
Case
Products Description
Modular display stands are available in multiple sizes to meet the needs of various business events, exhibitions, promotions, and conferences: such as 3*1, 2*2, 3*2, 3*3, and 3*4.
| series | Specification | Shelf dimensions | Shelf packaging mm | Weight (KG) |
| 75cm | 1X3 | 77*224 | 31*17*85 | 11 |
| 2X3 | 150*224 | 850*320*280 | 13 | |
| 3X3 | 224*224 | 850*320*280 | 15 | |
| 4X3 | 224*297 | 850*320*280 | 22 | |
| 5X3 | 224*370 | 850*320*280 | 27 | |
| 100cm | 1X2 | 198*101 | 1100*200*200 | 9 |
| 2X3 | 198*295 | 1090*320*290 | 20 | |
| 3X3 | 295*295 | 1090*320*290 | 25 | |
| 4X3 | 392*295 | 1090*320*290 | 27 | |
| 6x3 | 592*295 | 108*32*29 108*32*29 | 49 | |
| 8x3 | 792*295 | 108*32*29 108*32*29 | 60 | |
| Lighting the front desk | 1X1 | 101*101 | 1080*160*360 | 12 |
Details and LED light source
Connect the LED power supply (2-meter extension cord, compatible with 110-240V voltage), insert the silicone-edged canvas into the frame slot, and pull it taut to complete the installation.
Exhibition application solutions 3D design
Free design templates are provided, supporting 1440dpi high-definition printing. A 1/2″ bleed area is required.
Production capacity
FAQ
1. What precautions should be taken when using the power supply?
Wide voltage range of 90-260W, suitable for various designs; power consumption is only about 50W per square meter, saving more than 75% on electricity costs compared to traditional light boxes. The electricity savings over 2-3 years can cover the cost of the light box.
2. What are the advantages in terms of safety and environmental protection?
Low heat generation: The surface temperature is only 38℃, extending the lifespan of the image and avoiding fading or deformation caused by high temperatures; the aluminum alloy frame and transfer paper/polyester fabric are reusable, wrinkle-free, and washable.
3. What are the available sizes and styles?
Modular structure, each cell is 75cm or 100cm, and can be extended vertically, horizontally, or vertically. Individual cells can also be used independently, such as 2x1, 3x1, 1x1, 2x2, 3x2, 3x3, 3x4, 3x5, and 3x6. It can be used upright or vertically, and can be equipped with a reception panel. Easy installation and strong stability make it suitable for the "short-time setup" needs of exhibitions.
4. How to make the background wall more stable?
Lightweight yet strong: Adjustable aluminum feet and counterweight base, impact-resistant and resistant to light winds, preventing it from tipping over in the flow of people at exhibitions.
5. Is it convenient to exhibit abroad?
The ultra-compact display stand can be completely folded, with a thickness of only about 10 cm when folded. Some ultra-thin models are compressed to 8 cm, easily fitting into a suitcase or airline bag, making it suitable for domestic and international exhibition transport. For example, the standard 3x3 compartment model weighs 15 kg when folded and can be checked in with a canvas rolling suitcase.
